Panasonic HC-V770EB High Definition Video Camera - Black

Save Every Scene in Natural Beauty
Catch the scenes you want with easy zooming and excellent quality. Use the world’s first HDR (High Dynamic Range) Movie technology to get clear shots even with backlighting, and take sub camera shots with a smartphone.
Premium Picture Quality
With Advanced Lens, Sensor and Engine

The lens system drives each of four lens groups separately, reducing the drive ranges to result in high image quality, high-powered zooming, and a compact camera body. This combines with the BSI sensor, which features 6.03M effective pixels, and the high-speed Crystal Engine, for crisp, clear pictures.

HDR (High Dynamic Range) Movie
Clear Shots with Excellent Detail in Both Bright and Dark Areas

 By combining two images taken with different exposure times, the HDR Movie function suppresses blown highlights and blocked shadows for crisper, clearer videos. This is the world's first* consumer camcorder to feature the HDR Movie function. Even in difficult shooting situations, such as backlighting, you can easily capture natural videos with excellent gradation.
Wireless Twin Camera
Use Your Smartphone as a Sub Camera

 Using your smartphone with Wi-Fi operation as a sub camera, you can shoot from two angles at the same time. Since you are shooting with different cameras, you can use one at a distance, or at any angle you choose. This gives you a wide variety of Picture in Picture images.

20x Optical Zoom with
4-Drive Lens System
By driving each of four lens groups separately, the drive ranges are reduced, resulting in high image quality, high-powered zooming, and a compact camera body. This keeps the body compact even with a 20x optical zoom.
BSI Sensor
The Back Side Illumination Sensor has a large effective area with 6.03M effective pixels, suppressing noise even when shooting in dimly lit places, such as indoor scenes or nightscapes. It achieves stunningly beautiful images even down to the tiniest details.

Crystal Engine
Panasonic's unique, high-speed engine lets you shoot and play smooth Slow Motion Video in Full-HD. Its Noise Reduction function reduces noise for crisp, vibrantly colorful Full-HD images.
Level Shot Function
The Level Shot function automatically detects and corrects the tilting of captured images. The setting can be adjusted to one of three levels (OFF, Normal, Strong) depending on the shooting conditions.
5-Axis HYBRID O.I.S. +
HYBRID O.I.S. + uses five-axis correction to thoroughly suppress blurring all the way from wide-angle to powerful zoom shots. This lets you capture crisp, clear images without blurring, in almost every shooting situation.
High Quality Sound Recording
Wind Shield Zoom Microphone
A special damping material is provided in the space between the mic and the mic net to suppress wind noise for clear recording always



High-Quality Audio Parts

Four 6mm-diameter, high-S/N mics and aluminum electrolytic capacitors reduce sound distortion and increase clarity.
Full-HD Slow Motion Video
Records Full-HD (1920 x 1080) at 120 fps, and the Intelligent Frame Creation of the Crystal Engine interpolates to an equivalent of 240 fps, for smooth slow motion. Switches to slow motion while you touch the icon on the LCD screen during shooting.
Creative Control
Filter effects – Miniature Effect, 8mm Movie, Silent Movie and Time Lapse Recording – make it possible to shoot impressive video recordings that are matched to the shooting situation.
iA (intelligent Auto) /
iA Plus Mode
This powerful function senses the shooting conditions and automatically makes the settings and activates functions that deliver optimal results. In addition, the iA Plus Mode enables you to adjust exposure compensation and white balance by just pressing the button on the LCD.
Multi Manual Dial
By pushing or rotating the manual dial, you can easily adjust allocated functions, like focusing and changing the iris.

Adjustable Items


•Focus

•White Balance Mode

•Shutter Speed

•Iris

•Sharpness

•Color Saturation

•White Balance Fine

•Brightness
One-touch Connection
Without bothersome initial settings, NFC lets you connect a smartphone or tablet to the camcorder in one touch.
QR codes are also provided for use by those who don’t have an NFC phone.

Real Time Broadcasting
You can live-stream events on USTREAM as they are being recorded in Full-HD resolution.
Remote Shooting /
Remote View
The “Panasonic Image App” lets you use a smartphone or tablet as a live-view remote controller and operate the camcorder from a distance. Videos and photos inside the camera can be viewed on a smartphone or tablet, and uploaded to an SNS site.
Baby Monitor
You can check on the baby with a smartphone or tablet in another room. The Push Notification function alerts the smartphone or tablet if a voice sensor detects the baby waking up and crying.
Home Monitoring
When you are away from home, you can monitor and record there with high-quality live video, and speak to your family or pets using your smartphone or tablet.
Highlight Playback and Easy Share
You can enjoy Highlight Playback with a smartphone or tablet right after shooting. Favorite scenes can be shared on SNS with simple drag and drop operation.
Auto Transfer (Wireless PC Copy)
Images are transferred from your camcorder to a computer via the wireless access point at home.
Wireless TV Playback
An access point at home can be used to transfer data wirelessly to the TV or a tablet in the living room, or other rooms in the house. You can play images on the large-screen display.

Technical Specification:
SENSOR FOR MAIN CAMERA |
Image Sensor |
1/2.3 type (1/2.3") BSI MOS Sensor |
Total Pixels |
12.76 megapixels |
Effective Pixels (Motion Image) |
6.03 megapixels [16:9] (Level Shot Function OFF or Normal) |
Effective Pixels (Still Image) |
5.21 megapixels [3:2]/6.03 megapixels [16:9]/4.72 megapixels [4:3] |
SENSOR FOR SUB CAMERA |
Image Sensor |
- |
Total Pixels |
- |
LENS FOR MAIN CAMERA |
F Value |
F1.8 (WIDE) / F3.6 (TELE) |
Optical Zoom |
20x |
Focal Length |
4.08 – 81.6 mm |
35 mm Film Camera Equivalent (Motion Image) |
29.5 – 612 mm [16:9] (Level Shot Function OFF or Normal) |
35 mm Film Camera Equivalent (Still Image) |
33.5 – 669.9 mm [3:2]/29.5 – 612 mm [16:9]/36.2 – 724.6 mm [4:3] |
Filter Diameter |
49 mm |
Lens Brand |
Panasonic Lens |
LENS FOR SUB CAMERA |
F Value |
– |
Focal Length |
– |
35 mm Film Camera Equivalent (Motion Image) |
– |
CAMERA SECTION |
Standard Illumination |
1400 lx |
Minimum Illumination |
2 lx (Scene Mode Low Light 1/25), 1 lx (Night Mode (Color)), 0 lx (Night Mode (IR)) |
Focus |
Auto / Manual |
Zoom |
Intelligent Zoom OFF |
20x |
Intelligent Zoom ON |
50x |
Digital Zoom |
60x / 1500x (The maximum value of zoom magnification can be set in two patterns) |
White Balance |
Auto / White Set / Sunny / Cloudy / Indoor1 / Indoor2 |
Shutter Speed |
Motion Image |
[50p / 50i]/Auto Slow Shutter ON : 1/25 – 1/8000/Auto Slow Shutter OFF : 1/50 – 1/8000 |
Still Image |
1/2 – 1/2000 |
Iris |
Auto / Manual |
Image Stabilizer |
HYBRID O.I.S.+ with Active Mode, O.I.S. Lock, Level Shot Function |
Creative Control |
Miniature Effect, Silent Movie, 8mm Movie, Time Lapse Rec |
RECORDING SECTION |
Recording Media |
SD/SDHC/SDXC Memory Card |
Recording Format |
[AVCHD] AVCHD Progressive/[iFrame / MP4] MP4 |
Compression Method |
MPEG-4 AVC/H.264 |
Recording/ Playback Mode |
1080/50p (28Mbps / VBR), (1920 x 1080/50p)/PH (24Mbps / VBR), (1920 x 1080/50i)/HA (17Mbps / VBR), (1920 x 1080/50i)/HG (13Mbps / VBR), (1920 x 1080/50i)/HE (5Mbps / VBR), (1920 x 1080/50i)/MP4/2160p(72M) (72Mbps / VBR), (3840 x 2160/25p)/MP4/1080p(50M) (50Mbps / VBR), (1920 x 1080/50p)/MP4/1080p(28M) (28Mbps / VBR), (1920 x 1080/50p)/MP4/720p(9M) (9Mbps / VBR), (1280 x 720/25p)/iFrame (28Mbps / VBR), (960 x 540/25p) |
Actual Recordable Time with Supplied Battery |
Approx. 55 min (50p mode)/Approx. 55 min (PH mode)/Approx. 55 min (HA mode)/Approx. 55 min (HG mode)/Approx. 55 min (HE mode)/Approx. 50 min (MP4 50M)/Approx. 55 min (MP4 28M)/Approx. 1 h 00 min (MP4 720p)/Approx. 1 h 00 min (iFrame)/* Twin Camera OFF |
Thumbnail Display |
20 thumbnails/page, 9 thumbnails/page, 1 thumbnail/page |
Audio Recording System |
AVCHD: Dolby Digital (5.1ch / 2ch)/iFrame, MP4: AAC (2ch) |
Microphone |
5.1ch Surround, Zoom, Focus and Stereo Microphone |
Speaker |
Dynamic type |
STILL IMAGE SECTION |
Recording Format |
JPEG (DCF/Exif2.2) |
Recording Image Size |
Still Image |
[16:9] 24megapixels (6528 x 3672),12.6 megapixels (4736 x 2664), 2.1 megapixels (1920 x 1080)/[3:2] 20 megapixels (5472 x3648), 10.6 megapixels (3984 x 2656), 2.0 megapixels (1728 x 1152)/[4:3] 18 megapixels (4896 x 3672), 8 megapixels (3264 x 2448), 0.3 megapixels (640 x 480) |
Simultaneous Recording |
[16:9] 12.6 megapixels (4736 x 2664), 2.1 megapixels (1920 x 1080) |
Flash |
– |
GENERAL SECTION |
Power Supply |
3.6V (Battery) / 5.0V (AC Adaptor) |
Power Consumption |
Max. 6.7W (Recording) / Max. 7.7W (Charging) |
Dimensions (W x H x D) |
Approx. 65 x 73 x 139 mm (2.559 x 2.874 x 5.472 inch) |
Weight (w/o battery and SD card) |
Approx. 353g (0.778 lb) |
LCD Monitor |
7.5cm (3") Wide LCD monitor (460,800 dots) |
Touch Panel |
Yes |
View Finder |
– |
Manual Ring / Dial |
Yes (Dial) |
Interface |
AV |
Yes |
HDMI |
Yes (micro) |
Microphones (stereo mini) |
Yes |
Headphone (stereo mini) |
Yes |
USB |
2.0 Hi-Speed |
USB Charge |
Yes |
LED Video Light |
Yes |
Accessory Shoe |
Yes (cold) |
Lens Cover |
Yes (Auto) |
On-Screen Display Language |
English, German, French, Italian, Spanish, Polish, Czech, Netherlandic, Turkish, Swedish |
Wi-Fi |
Standard |
IEEE 802.11b/g/n |
Frequency |
2.4GHz band |
NFC |
Yes |
STANDARD ACCESSORY |
AC Adaptor |
Yes |
AC Cable |
– |
DC Cable |
Yes (USB Type) |
Rechargeable Battery Pack |
Yes (1,940mAh) |
Battery Charger |
– |
IR Remote |
– |
HDMI Cable |
Yes (micro) |
AV Multi Cable |
– |
AV Cable |
– |
Shoe adaptor |
Yes |
Lens Hood |
– |
USB Cable |
Yes |
Editing Software |
HD Writer AE 5.2 (Download) |
