Celestron NexImage 5 Solar System Imager (5MP)

Celestron NexImage 5 Solar System Imager (5MP)

Key Features

  • 5MP camera for telescopes
  • Easy to use
  • Image stacking for highest resolution
  • Breakthrough low-noise CMOS technology
  • PC software included
  • View and capture live video
  • Manually adjust settings
  • Machined aluminium 1.25” adapter barrel
AWAITING STOCK
Orders Accepted
Usually available in 5-7 days
Our Price
£259.00

Bundled Items

Total Price £259.00
£259.00
MPN Code 93711-CGL
EAN Code 050234937115
SKU 28137

Celestron NexImage 5 Solar System Imager (5MP)

Capture the stars in high-resolution with the Celestron NexImage 5 Solar System Imager. The 5MP colour sensor works with almost any 1.25” telescope to bring out tremendous detail of the planets, stars and astronomical anomalies.


5 Mega Pixel Colour Sensor

Take high-resolution 5-megapixel images with almost any telescope. The NexImage 5 Imager works with the included software package to bring out incredible detail that rivals those taken with much more expensive astronomical cameras. The System Imager records data in full colour with ON Semiconductor’s breakthrough low-noise CMOS imaging technology that dramatically reduces the image noise levels.


Control Your Images

Using the included iCap software you can manually adjust the gain, contrast, exposure time, frame rate and colour saturation using your PC. With this level of control, you can tailor the camera to each individual star or viewing environment for the best results every time.


Image Stacking

Take stacked images by recording a short video that the included RegiStax software analyses each frame of. The software automatically filters through the frames, discarding those of low quality, the remaining frames are layered on top of each other to create a high-quality image with maximum brightness, clarity, colour and detail.


Works in Light-Polluted Areas

The NexImage 5 Solar System even works in areas with relatively high light pollution. If you can see it in the sky then NexImage can photograph it.


Machined 1.25” Aluminium Body

The NexImage 5 is built out of machined aluminium that is lightweight but durable. With its 1.25” adapter barrel with C-threads, it can connect to almost any telescope, and can be used with standard 1.25” eyepiece filters.


Key Features

  • 5MP camera for telescopes
  • Easy to use
  • Image stacking for highest resolution
  • Breakthrough low-noise CMOS technology
  • PC software included
  • View and capture live video
  • Manually adjust settings
  • Machined aluminium 1.25” adapter barrel

View full specifications here >


What’s in the box?

  • 1x NexImage 5 Camera Body
  • 1x 1.25” Nosepiece
  • 1x Software CD
  • 1x USB 2.0 Cable
  • 1x Instruction Manual

Want to learn more?

Learn Astronomy Lingo: The Essential Astronomy Glossary


FAQs

Which telescope is this best paired with?

The NexImage 5 will work with almost any 1.25” telescope. For a perfect starter set-up, why not combine the NexImage 5 with the NexStar 5SE Telescope.

Should I buy the NexImage 5 or NexImage 10?

The two Solar System Imagers have their advantages, both are great for getting started in lunar, solar, and planetary imaging. Here are some of their main differences to help you choose which is right for you.



NexImage 10

NexImage 5

USB Power

High-speed USB 3.0, cable 10' long

USB 2.0, cable 5' long

Imaging Sensor

ON Semi MT9J003 CMOS

ON Semi MT9P031 CMOS

Frames per Second

Up to 94.4 (6.9 at full frame)

Up to 52.4 (6.0 at full frame)

Colour or Monochrome

Colour

Colour

Camera Resolutions (Px)

3872 x 2764

2592 x 1944

Number of Pixels

10.7 MP

5.0 MP

Sensor Size

6.4mm x 4.6mm

5.7mm x 4.28mm

Operating environment

-40°C to 40°C

-30°C to 70°C

Software Compatibility

iCap, IC Capture, DirectShow, oaCapture

iCap, IC Capture, DirectShow

I want to photograph using my DSLR camera, is this what I need?

If you are looking to use your DSLR or SLR camera then you need a T-Adapter and T-Ring.

You can find them on our website here >
